Brimstone Missiles In Ukraine

On 12 May video of what appears to be a test launch of Brimstone Missiles in Ukraine surfaced online. A containerised launch platform can be seen launching a salvo of three missiles. The footage shows what appears to be a repurposed commercial vehicle, such as an IVECO Daily or Mercedes-Benz Sprinter box van. The van appears to have a series of rails mounted inside the cargo area which may have something similar to a Cobham triple launch rail fixed to them. It could be described as a sort of very advanced technical. It is unclear when or where the footage was filmed.

Brimstone salvo being launched from a repurposed commercial vehicle (via Social Media)

In April, the UK Ministry of Defence confirmed the supply of Brimstone missiles to the Ukrainian Armed Forces. It was announced that these would be adapted for surface launch for use against ground targets. Before Russia’s invasion of Ukraine in February, the UK government had been in talks to provide the maritime variant of of the missile (Brimstone Sea Spear) to the Ukrainian Navy and there was speculation that this would be the variant sent to Ukraine. However, on 25 April, Defence Minister Ben Wallace told the UK Parliament that “if we do provide Brimstone, we will look to provide it for the land, using stock that we already hold, but not as yet for the sea.” A day later, on 26 April, the UK’s Armed Forces Minister James Heappey told Parliament that “such is the speed with which our technicians are now working and so effective is the partnership with industry that I am pleased to say that that has been moved forward. It is necessary to inform the House that we will be providing Brimstone in the next few weeks.”

Brimstone is an advanced, rocket-powered, radar-guided weapon which can seek and destroy armoured targets at long ranges with high precision. Developed by in the late 1990s it was designed to be fired from aircraft and entered service with the Royal Air Force in 2005, seeing action in Iraq, Afghanistan Libya and Syria. The missile’s manufacturer MBDA has continued development of the weapon with ground-based and maritime variants designed and proposed. Brimstone uses a 94 Ghz the radar seeker and a sophisticated guidance system which can differentiate and prioritise targets. The missile delivers a tandem shaped charge to destroy armoured targets at ranges varying from 12 to approximately 20km depending on launch platform and conditions and the variant of missile. Brimstone is capable of firing a salvo of missiles which will then fly in parallel before striking their targets in unison. This may be what is seen in the video. Brimstone is a fire and forget missile with the missile able to targeted at a designated killbox to then engage highest value targets it detects.

Diagram showing the layout of Brimstone (via Think Defence)

On 6 May the first evidence of Brimstone’s presence in Ukraine was provided by a series of photographs of the remnants of a Brimstone 1 missile. The recovered tail section of the missile bore a sticker denoting the surviving component as being manufactured in September 2001. Subsequent photographs of fragments from another missile, which perhaps self destructed, surfaced online on 11 May. These suggested that this Brimstone 1 was manufactured in around May 2001.

On 8 May photographs of a further Brimstone 1, this time intact perhaps photographed before launch or after a failure of some sort, appeared online. If photographed following a failure it would indicate that this missile’s self destruct failsafe did not activate. Though the missile appears in good condition if it landed after a failure. From its markings seen in the photographs it is clear that the weapon’s components were produced in September 2001 and February and June 2004. We do not yet know how Ukrainian forces are employing Brimstone or how effective it has been.

Further footage from Ukrainian Brimstone launches emerged on 15 May, showing some close-ups from inside the launch vehicle. A Cobham triple rail can be seen mounted and several launches were shown as part of a compilation video shared by Ukrainian forces. In this video we only see two missiles being launched rather than a salvo of three although in one clip we can see three missiles mounted on the rail. The footage also shows us that the system appears to be mounted on a palletised frame work which could seemingly be easily mounted on more capable vehicles.

Brimstone offers greater range than the infantry-operated anti-tank guided missiles (ATGM) like the western Javelin or the Ukrainian Stunga-P. This greater range coupled with its ability to be fired in salvos offers a valuable capability to Ukrainian forces.


If you enjoyed this video and article please consider supporting our work here. We have some great perks available for Patreon Supporters – including custom stickers and early access to videos! Thank you for your support!


Bibliography:

Brimstone, MBDA, (source)
Brimstone Guided Missile, Think Defence, (source)
Footage: Brimstone Missiles Deployed in Ukraine, Overt Defense, (source)
What is the Brimstone missile?, BBC, (source)
Ukraine Update 25 Apr. 2022, UK Parliament Hansard, (source)
Ukraine 26 Apr. 2022, UK Parliament Hansard, (source)

Ukrainian Tavors – Fort-221 / Fort-224

In this video/article we’ll examine Ukraine’s other bullpup – the Fort-221 – the Ukrainian Tavor.

In a recent video/article we looked at the Ukrainian designed and produced IPI Vulcan, a bullpup based on the AK platform, and the two have been confused in some media. The Fort-22 series Tavors originate from Israel’s IWI. Introduced in the early 2000s the IWI Tavor has been purchased and seen service with militaries around the world. Ukraine’s Tavors were offered by RPC Fort or State Research and Production Association “Fort” of the Ukrainian Ministry of Internal Affairs. The company was originally established in 1991, initially as a regional organisation and in 1998 it became a state enterprise. Located in Vinnytsia, in western Ukraine, the company initially focused on a line of pistols, pump-action shotguns and AKM variants.

National Guard personnel armed with Fort-221 with M5 optics (Ukrainian National Guard)

From a survey of Fort’s website we know that IWI weapons first began to appear in the company’s product lists in late 2008 following an agreement to potentially license manufacture IWI products in Ukraine. This included pistols, submachine guns, rifles and the Negev light machine gun.

In 2011-12 media reports suggested the Tavor was being produced in Ukraine and the guns appeared at a number of trade shows with RPC-Fort markings, including a company crest in the moulded stock. There is, however, some doubt about whether the weapons were manufactured in Ukraine, merely assembled or if they were produced in Israel with some Fort markings and shipped to Ukraine. The nature of the partnership is undisclosed but it has been suggested that if Fort gained substantial sales for the weapons then further manufacturer may have been transferred to Ukraine.

Close up of the RPC Fort on a 5.56×45mm Fort-221 (Ukrainian National Guard)

In 2014, Colonel Vitaly Otamaniuk, the head of the artillery and missile management board of the Ukrainian Armed Forces, announced that the Fort-221 and Fort-223/224 carbines were adopted for arming the Ukrainian army, with an initial 500 ordered. While no further orders were publicly recorded we know that Police and internal security forces were issued the rifle as of 2016. The adoption of the rifles by Ministry of Internal Affairs units and the Ukrainian National Guard (which falls under the Ministry’s control) may be explained by the fact the Ministry owns RPC Fort.

Various Fort-22 series rifles on display (Ukrainian National Guard)

From photographs released before the February invasion we know that National Guard units including the Special Purpose units like the “Scorpion” Special Forces Detachment (Nuclear industry protection) and elements of the Special Operations Forces or SSO. These units are believed to include the 1st and 3rd Special Purpose Detachments based in Kyiv and the 8th Special Purpose Regiment in Khmelnytskyi as well as elements of the Ukrainian Ministry of Internal Affairs.

Member of the Ukrainian armed forces with a Fort-224 carbine (via social media)

There is some confusion around the Fort-22 series’ designations. From Fort’s website, circa 2020, we can see here that the majority of the IWI rifle range was on offer. There is some confusion around the designations with Fort-222 and Fort-223 not being listed here but there are photographs of Fort-223 marked 5.56  X-95 pattern guns seen trade shows, which suggests that for a time at least the 223 designation was used. But as we’ve seen from Fort’s 2010 website Fort-223s were not listed. The Tavors are listed as follows:

  • Fort-221 in 5.56x45mm and 5.45x39mm (TAR-21) – 468mm / 18.4in
  • Fort-224 in 5.56×45 and 5.45x39mm (X-95) – 330mm / 13in
  • Fort-224 in 9×19 (X-95 SMG) – 330mm / 13in

We can also see that the Uzi Pro is listed as the Fort-226 while the 5.56x45mm Galil Ace is listed as the Fort-227, the 7.62x39mm chambered version is the Fort-228 and the 7.62x51mm version is the Fort-229. The Ukrainians designed the Galatz accurised Galil the Fort-301 and the Negev light machine gun the Fort-401 both of which have been fleetingly seen in the field.

Further survey of Fort’s website shows that the Tavor series of rifles ceased to be listed on the page in March 2021 and IWI and Meprolight were removed from the site’s ‘Partners’ section in April 2021. Perhaps suggesting the end of the IWI-Fort partnership. The Tavor-pattern rifles are not listed by SpetsTechnoExport, Ukraine’s state export enterprise, but the IPI Vulcan is.

Member of the Ukrainian armed forces with a Fort-221 rifle (via social media)

Despite this we have seen a considerable number of the Ukrainian Tavor variants in the field. Since the Russian invasion in February the Fort-22 series have been most frequently seen with internal security forces and Ukrainian Army and National Guard special forces.

Within 48  hours of the Russian offensive Russian forces shared videos from what was said to be a captured Ukrainian National Guard depot. The video shows more than a dozen Fort-221s piled on top of crates. Around the same time they were seen to be equipping Ukrainian forces said to be linked to the Azov Brigade.

Members of the Ukrainian armed forces with a Fort-224 carbines (via social media)

On 7 March former Ukrainian presidents Petro Porochenko and Oleksandr Turchynov were seen. Rallying Territorial Defence Force units in Kyiv, Turchynov was seen armed with a Fort-221.

On 9 March an unknown number were captured by Russian forces which seized the National Guard armoury near the Zaporizhzhia Nuclear Plant. At least one Fort-221 was shown by Russian state media.

A Fort-224 in 9×19mm (via social media)

The Ukrainian Tavors continue to surface in imagery from the conflict but it is difficult to tell where they’re being used and by which units.

Both the Fort-221 rifle and the 224 carbine have been seen in the field, though it is often difficult to determine their chambering as the clearest indiction – the shape of the magazine – is invariably tucked under the user’s arm.  They are most often seen equipped with Meprolight M5 and M21 sights and a number of the weapons have also been seen to be sporting camouflage paint jobs.

Thank you to those who have helped me collect images of the Ukrainian Tavors in the field, including Sad_Sand and DixieMauser and thank you also to Remigiusz Wilk.


If you enjoyed this video and article please consider supporting our work here. We have some great perks available for Patreon Supporters – including custom stickers and early access to videos! Thank you for your support!


Bibliography

Interpolitex 2011, Vitaly Kuzmin, (source)

Ukraine Manufacturing Tavor in 5.45x39mm, TFB, (source)

Shield and Sword of Ukraine: Main Achievements of thr Defense Industrial Complex for 2017, Defense Express, (source)

Fort.vn.ua, via WayBack Machine, (source)

Kyiv Police being introduced to 9x19mm Fort-224 carbines in 2016, Kyiv Police, (source)
