Breakdown: How Many Ukrainian Troops Has the US Trained?

The US Department of Defense recently announced that they would be expanding their training of Ukrainian personnel in January. The new training program will aim to train 500 Ukrainians per month giving them instruction on combined arms operations and tactics from the squad to the battalion level.

Long before the Russian invasion of Ukraine in February the US and other NATO nations had been heavily engaged in training the Ukrainian military to NATO standards. The US, UK and Canada established a Joint Commission for Defence Reform and Security Cooperation In July 2014, which later expanded. The Canadian training operation was known as Unifier while the British operation was known as Orbital, which has now   been superseded by Operation Interflex.

M109, HIMARS (in the field) and M119

Just before that announcement, however, the US also confirmed how many Ukrainian personnel have been trained so far. A US European Command Spokesperson shared a breakdown of how many troops have been trained on a number of major systems.

In a statement a European Command spokesperson told me that:

“Training is key to Ukraine’s continued success on the battlefield by ensuring that Ukraine has the skilled forces necessary to sustain its efforts to push back on Russian aggression. Since the U.S. started to provide security assistance to support Ukraine in defense of their nation, the United States has trained approximately 3,100 members of the Ukrainian Armed Forces”.

The breakdown of training provided to Ukrainian personnel covers a number of different systems and platforms:

The system which has seen by far the largest number of Ukrainian troops trained is the M777 155mm howitzer. As of 9 December the US has provided Ukraine with ‘142 155mm Howitzers and up to 1,004,000 155mm artillery rounds’. To operate these guns in the field the US has trained approximately 870 Ukrainian gunners. In addition to this 310 personnel have been trained on the M109 155mm self-propelled howitzer, M109s have been donated by the US, UK and Norway.

Other troops have been trained on the lighter 105mm M119 howitzers, 36 of which have been provided by the US with further guns coming from the UK. Around 500 Ukrainian gunners have been trained on the 105mm howitzers by US personnel, with more being trained in the UK by a multi-national training cadre. 220 Ukrainian personnel have also received training on the M120 mortar.

Finally, US EUCOM’s breakdown outlined that approximately 610 Ukrainian personnel have been trained on the M142 High Mobility Artillery Rocket System. So far 38 227mm HIMARs have been transferred to Ukraine by the US.

A U.S. Soldier assigned to 1st Armor Brigade, 3rd Infantry Division works with an Armed Forces of Ukraine soldier during M109 Self-Propelled Howitzer maintenance training at Grafenwoehr Training Area, Germany, May 25, 2022. The course is provided by the US and Norway as part of their respective security assistance packages. (U.S. Army photo by Spc. Nicko K. Bryant Jr., 7th Army Training Command Combat Camera)
Armed Forces of Ukraine Soldiers conduct drivers training on the M113 Armored Personnel Carrier as part of the maintenance course provided at Grafenwoehr Training Area, Germany, June 2, 2022. Instruction for the course is provided by the U.S. as part of a security assistance package. (U.S. Army photo by Sgt. Spencer Rhodes, 53rd Infantry Brigade Combat Team)

US personnel have also provided training on a number of vehicles, training 140 Ukrainians on M113 armored personnel carriers. With all of the vehicles and weapon systems it is unclear what ratio of these troops included instructors, mechanics and crews. At the time of writing the US has provided 200 M113s with European allies providing including Denmark, Spain, the Netherlands, Australia, Germany, Portugal, Lithuania and Austria also providing a similar number of M113 variants. The EUCOM spokesperson also noted that an unspecified number of Ukrainian troops had been trained on the M1089 Wrecker, a recovery vehicle which is part of the Medium Tactical Vehicles family. The latest Department of Defense factsheet on equipment provided to Ukraine notes that “22 Tactical Vehicles to recover equipment” have been transferred.

While the provided breakdown of systems Ukrainian troops have been trained on by US personnel outside of Ukraine isn’t exhaustive it also included 450 personnel who have received training on ‘other’ systems such as the M1089 and various Unmanned Aerial Vehicle platforms.

Much of this training has been carried out at US military sites in Poland and Germany but as we’ve already seen in previous videos Ukrainian troops are also being trained in the UK by a multi-national training force, in Lithuania and elsewhere.

This article was adapted from my earlier article at Overt Defense.

Support Us: If you enjoyed this video and article please consider supporting our work here. We have some great perks available for Patreon Supporters – including early access to custom stickers and early access to videos! Thank you for your support!

Sweden’s KSP-58 Machine Guns In Ukraine

Since the Russian invasion of Ukraine in February we’ve seen a number of FN MAG variants appear in use with Ukrainian forces. By far the most common appears to be the US M240 series. However, in recent months we’ve also seen a number of Swedish KSP-58s appear in imagery from the field.

Sweden has long supported the Ukrainian war effort providing a shipment of 5,000 Pansarskott m/86 anti-armour weapons (perhaps better known as the AT4) back in late February. The transfer of an additional batch of 5,000 m/86s was announced on 2 June. Most recently on 30 June it was reported that Sweden would provide a fresh batch of light anti-armour weapons and also machine guns as part of a transfer worth $49 million. When delivery of this aid was made is unconfirmed but the KSP-58s are reported to have been in theatre possibly as early as July – August.

While the type of machine gun was not confirmed, since the beginning of September we’ve seen imagery of a number of KSP-58 GPMGs appear in theatre. Easily identified by their wooden stocks, grey-green-coloured receiver finish and enclosed front sight. Sweden was one of the earliest adopters of the FN MAG and the Kulspruta 58 or KSP-58 entered service with the Swedish armed forces in the late 1950s and was originally chambered in the 6.5×55mm Swedish round. The KSP-58B was introduced following the adoption of 7.62x51mm. The guns were made under license from FN at the Carl Gustav Stads rifle factory in Eskilstuna.

A KSP-58B in use with Ukrainian troops c. September 2022 (via social media)

These have been seen in the hands of International Legion units and also regular Ukrainian Army units centred around Mykolaiv and Kherson. All the the examples of the weapon sighted appear to be KSP-58Bs, none of the guns seen have the Picatinny rails seen in the KSP-58F.

Speaking to Kaiser [frontline_view_kaiser] a German volunteer with the Ukrainian Army, he said his unit encountered a “a brand-new, never used KSP with original factory delivered Box and all accessories untouched”. His colleague Yuri [nucking_futs_yuri] has shared some videos filmed in late-August, during a training session he ran on FN MAG variants for various Ukrainian units. Yuri said their were about 20 guns on the range during the training session, with the majority being KSP-58s. Yuri shared a video in mid-September firing a through a KSP-58B, from the hip, filmed after the training session had been completed.

Yuri with a KSP-58B c. September 2022 (nucking_futs_yuri)

While we can’t confirm that the KSP-58s came directly from Sweden it seems likely. Another potential origin for the weapons may be the Baltic States (Estonia, Latvia and Lithuania). Sweden gifted an unconfirmed number of KSP-58s to the Baltic States in the 1990s. Today, the guns remain in service with the Latvian Army and National Guard, the Estonian Army and Estonian Defence League and the Lithuanian Army and National Defence Volunteer Force. Both Estonia and Lithuania began searching for a replacement for the KSP-58 in mid-2021. Given the Baltic states’ support for Ukraine the guns may potentially have originated from there, rather than Sweden itself. We have already seen the Baltic States have transferred former Swedish equipment including the PV-1110 recoilless anti-tank gun which were given to the Baltic states in the early 1990s.

It remains to be seen if we’ll see more of the KSP-58s in the field but in future articles/videos we’ll look at other FN MAG variants are in use in Ukraine.

Thank you to Kaiser and Yuri for their input – definitely check them out on their social media!

If you enjoyed this video and article please consider supporting our work here. We have some great perks available for Patreon Supporters – including custom stickers and early access to videos! Thank you for your support!

Bibliography:

Kulspruta 58, Forsvarsmakten, (source)

KSP-58, Soldf.com, (source)

Sweden to boost military aid to Ukraine, Politico, 29 Aug. 2022, (source)

Sweden to send military aid to Ukraine, Reuters, 27 Feb. 2022, (source)

Sweden assists Ukraine with the Robot 17, SVt.se, 2 June 2022, (source)

Sweden to send more anti-tank weapons and machine guns to Ukraine, Reuters, 30 June 2022, (source)

Estonia to acquire new weapons for EDF, Defense League, ERR, 18 Nov. 2022, (source)

Lithuania buys machine guns for EUR 34 million, Defence 24, 20 Aug. 2022, (source)

RPG-30: Russia’s Dual Tube Rocket Launcher

The RPG-30 is one of Russia’s more advanced disposable anti-armour weapons. Developed in the early 2000s by Bazalt it is designed to overcome reactive armour and active protection systems. It entered service in 2012 and has seen extensive use during the fighting in Ukraine.

The 7P53 RPG-30 “Kryuk” or ‘Hook’ is a 105mm fin and spin stabilised rocket propelled munition with a tandem HEAT shaped charge warhead. The RPG-30 overcomes ERA and APS by using a 42mm IG-30 decoy projectile, which is believed to be inert, coupled with the main rocket’s tandem warhead. This can be seen in a secondary, thinner tube running along the side of the weapon. The precursor decoy causes premature activation of the APS and allows the main warhead to exploit the gap in the tank’s protection. The theory being that the target’s APS takes some time, perhaps half a second, before it can engage again. The gap between the firing of the two rockets is measured in milliseconds and the lag does not appear to be significant enough to effect the user’s aim or accuracy on target.

RPG-30 (Vitaly Kuzmin CC BY-SA 4.0)

The RPG-30 uses the PG-30 tandem HEAT warhead, similar to the PG-27 used by the RPG-27. It can reportedly penetrate 750mm of rolled homogeneous armour and up to 650mm of rolled homogeneous armour after ERA. Effective range estimates vary with the average suggesting 200m.

The weapon’s sights are simple and consist of a folding ladder front sight and rear sight – there does not appear to be provision for mounting optics. Flipping up the rear sight also cocks the weapon. The disposable tube(s) is made of aluminium with a fibreglass outer layer. Sources suggest it weighs around 10.3kg (22.7lbs) and has an overall length of just over 1m (1,135mm/44.7in).

A pair of RPG-30s captured in April 2022 (via Social Media)

Unlike other Russian weapon systems few videos of its use have been shared by Russian state media or Russia’s defence exports corporation Rosoboronexport. The ongoing war in Ukraine, however, has provided our first real look at the weapon in action. As soon as the Russian invasion was launched on 24 February, RPG-30s began to be seen in use with Russian forces. By late February and early March imagery of captured examples was shared on social media.

Russian soldier posing with RPG-30, March 2022 (via Social Media)

The first images of the weapon came from Russian sources in late February, just after the invasion. This was quickly followed by imagery of captured examples, most notably from the column of Tigr-M armoured infantry mobility vehicles in Kharkiv.  A photograph of a further two captured RPG-30s appeared in April, while another example was photographed in Donbas in early May. Later in May a photo of a Russian soldier posing with one was shared on social media and in September significant caches of weapons were captured in Kherson and Balakliya.

Still of a Russian soldier firing an RPG-30, August 2022 (via Social Media)

In late August we got our first brief look at the RPG-30 being fired in a montage video of VDV weapon systems (see image above). Earlier in mid-August a sort of ‘unboxing video’ was shared giving us a good close up look at some of the packaging the RPG-30s are shipped in and the markings on the side the weapon. Most recently in some further video of the RPG-30 being fired on a Russian Western Military District range also surfaced giving us a good look at the weapon in action.

RPG-30s captured in April (via Social Media)

Of course the weapon is designed to be simple to use, anyone with training on a similar shoulder-fired disposable anti-armour weapon can operate it. While it has been said that its widespread use in Ukraine is somewhat ironic given that Ukraine does operate any APS equipped tanks, the weapon is still useful against less sophisticated tanks. While the precursor might potentially deliver some limited kinetic damage to the ERA block, the RPG-30’s tandem warhead is capable of defeating the ERA fitted to most Ukrainian tanks, though of course, the same can be said of Russia’s other anti-armour weapons which use tandem warheads.

Update 27/10/22:

The Georgian Legion recently shared a short video looking at a captured RPG-30. The video also includes firing footage of the weapon.

If you enjoyed this video and article please consider supporting our work here. We have some great perks available for Patreon Supporters – including custom stickers and early access to videos! Thank you for your support!

Bibliography:

105mm PG-30 Rocket, CAT UXO, (source)

RPG-30 Kryuk (Hook), US Army TRADOC, (source)

Russian Army receives cutting-edge antitank rocket launchers, TASS, (source)

PTKM-1R: Russia’s Most Advanced Anti-Tank Mine

In recent weeks Ukrainian forces have shared photographs of captured PTKM-1R mines. These are without doubt Russia’s most advanced anti-tank mine design. The PTKM-1R’s main feature is that it is a top attack munition, much like a Javelin or NLAW. It can strike down from above at a tank’s least protected point – its roof and engine deck.

PTKM-1R photographed in Ukraine in April 2022 (via social media)

The mines essentially brand new and were only publicly unveiled by Rosoboronexport in November 2021 at the Army 2021 exposition and later at EDEX 2021. They have been adopted by the Russian armed forces on a limited basis. The PTKM-1R was first seen in Ukraine back in late April, appearing to show it deployed. Russia have released no footage of the mines in action.

PTKM-1R submunition detonating and projecting its EPR down on a target during a 2021 demonstration (Rosoboronexport)

The PTKM-1R is a top-attack anti-tank/anti-vehicle mine which is designed to detect the passage of target vehicles using acoustic and seismic sensors. The launching charge then detonates and projects a submunition up into the air toward the target. As the sensor-fuzed submunition flies over the target and detects movement below it detonates firing an explosively formed penetrator (EFP) down onto the vehicle – attacking it where its armour is weakest.

Sectioned PTKM-1R (Rosoboronexport)

The mine can engage targets at between 5 and 50m but can detect a target out to 100m. Targets are initially identified by the mine by comparing the detected signature with acoustic and seismic signatures in its internal database. Once a target is detected the mine calculates a flight path and the launch unit tilts 30-degrees toward the target to create a parabolic ballistic trajectory over the target. While the mine can detect targets in a 360-degree arc the mine itself has a limited arc, limited by the need to tilt before firing, the mine has a an arrow with ‘towards target’ for orientating the mine in the direction of expected engagement but in an Army 2021 presentation Rosoboronexport suggest that the mine can turn itself to face its target, and track it if needed.

Rosoboronexport graphic showing the trajectory of the PTKM-1R (Rosoboronexport)

The submunition is launched into the air at a speed of 30m/s to a height of approximately 30 metres. It then uses infrared sensors and radar to pinpoint its target before detonating its shaped charged to create an explosively formed penetrator. Rosoboronexport claim the mine can penetrate ‘at least 70mm’ of armour.

The PTKM-1R can be considered an off-route mine like the German DM-22 and Estonian PK14s which are known to be in use with Ukrainian forces but its ability to strike from above sets it apart. The nearest similar system is the short-lived US M93 Hornet developed by Textron in the 1980s.

PTKM-1R captured in its transit chest, 10 September (via social media)

The launch unit (or transporter-launcher) incorporates eight feet that are lowered when the mine is deployed these provide a stable platform. According to Rosoboronexport the PTKM-1R weighs 19.9kg while its payload is said to be around 2.8kg of explosive. Two seismic sensors, which sense the vibrations caused by approaching vehicles, are deployed and there are also four cardiod microphones at the top of the unit which listen for the sounds of heavy armoured vehicles.

PTKM-1R captured by Ukrainian forces during Kharkiv offensive, 10 September (via social media)

On around the 10th September a second mine was photographed showing an undeployed PTKM-1R still in its transit chest. The mine was captured, reportedly by SSO, in the Kharkiv region on the eastern front where fighting has been significant and Russian forces appear to be rapidly falling back.

Update 17/10/22: On the 17th October, Ukrainian Telegram channels began sharing a short video of a PTKM-1R which appears to have launched its top-attack munition. The Telegram posts did not state where the footage was filmed. In the video we can see that the mine’s base unit has angled (supposedly towards its target) and has launched its munition.

Update: 23/11/22: A video from the DPR/DNR People’s Militia Press Office featuring a Russian sapper (possibly from the 56th Guards Air Assault Regiment operating in the Zaporizhzhia Oblast) explaining the deployment of the advanced Russian PTKM-1R top-attack mine. [Machine translation in video captions] H/t – Patrick Senft.

Update 26/11/22: Photographs of a deployed and detonated PTKM-1R have surfaced online.

Update 5/12/22:

Update – 2/02/2023: A short clip was shared on Telegram showing an intact and unfired PTKM-1R said to be in the Kherson region.

Update – 07/06/23: A recent sighting on a PTKM-1R from drone footage.

If you enjoyed this video and article please consider supporting our work here. We have some great perks available for Patreon Supporters – including custom stickers and early access to videos! Thank you for your support!

Bibliography

Russian PTKM-1R Top-attack Anti-vehicle Mine Documented in Ukraine, ARES, (source)

PTKM-1R: Top-Attack Anti-Tank Mine, Rosoboronexport, (source)

PTKM-1R Landmine, Cat-UXO, (source)

PTKM-1R, Fenix Insight, (source)
