Does the L403A1 Mount a Bayonet?

In a recent article/video we looked at the UK’s newly selected Alternative Individual Weapon system, the L403A1. The Knight’s Armament KS-1 was selected as the new rifle for the Ranger Regiments of the Army Special Operations Brigade and for elements of the Royal Marines Commandos.

One question which frequently appeared in the comments was “can it fit a bayonet?” This is a good question because the British Army is known to be a proponent of bayonet use with a long history of using it to great effect from the 1600s right through to recent conflicts in Iraq and Afghanistan.

Surveillance and Reconnaissance Squadron member with new L403A1 (Royal Marines Commandos)

The short answer to the question is – yes. The longer answer is a bit more complex. Just a week after the selection of the new rifle was announced Knights Armament displayed one of the rifles with a bayonet fixed at the DSEI 2023 exposition in London. This naturally caught some attention.

L403A1/KS-1 with a bayonet seen as DSEI 2023 (via social media)

However, when the selection of the L403A1 was initially announced a breakdown of the Alternative Individual Weapon system’s accessories and ancillaries was released. This included: a Vortex 1-10x LVPO, an Aimpoint ACRO and a QDC/MCQ-PRT [Quick Detach Coupling/Mini Close Quarters–Pressure Reduction Technology] suppressor along with a sling, a vertical front grip, and a Surefire weapon light but noticeably it did not include a bayonet.

Breakdown of the parts and accessories adopted with the L403A1 (Edgar Brothers)

The ability to fix a bayonet was not part of the weapon’s original requirements and it was not stipulated by the Rangers or Commandos. Instead, Knight’s Armament developed the capability themselves, perhaps recognising the UK’s fondness for the bayonet and the British Army’s long history of its use as both a training aid and as a weapon of war.

KAC’s 1st bayonet design with QDC attachment mechanism (courtesy of Gregory Knowles)

TAB reached out to Knight’s Armament about the bayonet and they confirmed that “the bayonet was designed in anticipation of a potential need, though not required as part of the contract.” The bayonet seen fixed to the rifle at DSEI was apparently the first iteration of the design which according to Knight’s Armament “used the same mounting mechanism as the suppressors” but a new “revised design uses an attachment mechanism that is more similar to the SA-80 bayonet attachment/retention design.”

Essentially, rather than using the suppressor’s ‘Quick Detach Coupling’ system the newer iteration of the bayonet uses a pivoting catch. The quick-detach method used by the suppressor involves the suppressor being rolled one way until the index pin seats in a notch before tightening it by twisting it the other direction.

Photos of 2nd bayonet design (Knight’s Armament Company)

The new iteration of the bayonet fits over the rifle’s 3-prong QDC muzzle device and uses the same style of catch system as the SA80. Knight’s Armament explained that “the redesign was a refinement of an initial concept after some basic testing and feasibility evaluation.” The bayonet haven’t undergone any serious testing as they’re still in the development phase. A chromed version of the latest iteration of the bayonet was also displayed at DSEI and has a removable pommel piece that can act as a small storage space and makes the bayonet more comfortable for use as a knife.

The bayonet’s blade is offset to the left side with a corresponding hole which lines up with the muzzle.

While bayonets aren’t currently planned to be issued with the rifles, the requirement might develop once they enter service. If, in the future, the UK Ministry of Defence requested a bayonet for the new rifles it seems that Knight’s Armament could be able to oblige.

Gulf War Homemade SA80 / L85A1 Front Grip

There is a rich history of attaching home-made, ad-hoc forward grips to weapons within the British military. In the 1940s troops fashioned home-made forward grips for Sten machine carbines while in the 1960s at least one member of the SAS operating in Borneo during the Indonesian Confrontation attached a carved wooden foregrip to his M16. In the 1980s the operators with the SAS’ counter-terrorism teams attached L1A1 SLR pistols grips to their MP5s.

British troops in Northern Ireland with L1A1s fitted with makeshift front grips made using a spare pistol grip attached with a jubilee clip

The intermittent tradition appears to have continued into the early 1990s with one member of the Staffordshire Regiment seen to have mounted a pistol grip to the forend of his L85A1. The soldier and his adapted rifle appeared in a number of photographs and some footage taken during a field exercises in Saudi Arabia.

Commandos on parade with STEN MkIIs equipped with ad-hoc front grip, at Kabrit in June 1943 (IWM A17755)

The battalion deployed to Saudi Arabia as part of 7th Armoured Brigade in October 1990, as part of Operation Granby. During the phase of operations in the Gulf which the US designated Operation Desert Shield allied forces prepared to liberate Kuwait and took part in a number of field exercises.

On 10 November, 1990 Sgt. Dave Miles, a British Army photographer filmed up-close footage of C Company, 1st Battalion during a live fire exercise. During one brief section of the footage the L85A1 with foregrip can be seen firing. On 6 January 1991, C Company took part in another live fire exercise which again saw them filmed and the same rifle features in several brief sections. It also appears in photographs taken by AP photographers Patrick Baz and Sadayuki Mikami, an unnamed British Army photographer and US Army photographer PFC John F. Freund.

Company C, 1st Battalion, The Staffordshire Regiment, during a live fire training exercise assaulting a mock village and trench complex, 6 January 1991. (XVIII Airborne Corps History Office photograph by PFC John F. Freund)

Unlike some of the earlier examples of wooden ad-hoc foregrips this one appears to be fashioned from a spare SA80 pistol grip attached to the rifle’s plastic forend by a bolt. While mods like this one weren’t that uncommon they are rarely so well documented in photographs and videos. It’s also interesting to see just how common painting weapons was.

Royal Marines Commandos in Afghanistan c.2006. An LSW rear grip fitted as an ad-hoc foregrip (Commando: On the Front Line)

Similar modifications were made using the rear grip from the L86A1 Light Support Weapon. These were again bolted through the vents in the underside of the rifle’s plastic handguard. One of these modifications was seen a number of times in the hand of a member of the Royal Marines Commandos during the 2007 documentary Commando: On the Front Line.

Generally the addition of foregrips make for handier, more pointable weapons. Arguably, the soldier from C company was ahead of his time as later, following the L85A2 refits and the Afghanistan urgent operational requirements, Grip Pod vertical front grips were paired with the rifles.

If you enjoyed this video and article please consider supporting our work here. We have some great perks available for Patreon Supporters. You can also support us via one-time donations here. Thank you for your support!

Project Hunter: The UK’s New Assault Rifle

The United Kingdom has announced the selection of the Knight’s Armament Company KS-1 as the new individual weapon for the new Ranger battalions and the Royal Marines Commandos. The requirement for the new rifle was released back in August 2021, and called for the “procurement and support of an Armalite Rifle (AR) platform Alternative Individual Weapon (AIW) System.”

The requirement called for a ‘Rifle System’ which comprises the weapon and a ‘Signature Reduction System’ [suppressor] and an ‘Optic System’. The rifle itself had to be ‘gas operated with a rotating, locking bolt’ and was to specifically have “a standard configuration, not bullpup, with the magwell in-front of the trigger housing.”

Royal Marines Commando with L403A1 (Royal Marines/Royal Navy)

The UK launched Project Hunter to select a new Alternative Individual Weapon (AIW) to replace the SA80/L85 series of rifles and Colt Canada L119s in service with the Rangers and elements of the Royal Marines Commandos. After two years of competition the UK MoD has announced that Knight’s KS-1 has been selected as the L403A1, beating off reported competition from Heckler & Koch, SIG Sauer, Daniel Defense and Glock.

Other weapons believed to have been evaluated include the HK416A5, the SIG Sauer SPEAR-LT, the Daniel Defense M4 and Glock’s GR-115F. Other companies believed to have submitted rifles include Colt Canada, Lantac, Haenel and Steyr amongst others.

The new rifles will supplement the L85A2 and L85A3 which currently equip the majority of the UK armed forces. The rifles will be procured via UK-based company Edgar Brothers and the £90 million ($110 million) contract will see up to 10,000 new rifles delivered over the next decade. An initial £15 million order for 1,620 AIW systems has been placed with the British Army fielding them with the Army Special Operations Brigade, with the brigade expected to receive the first rifles by the end of 2023. The Royal Marines’ ‘strike companies’ and Surveillance and Reconnaissance Squadron will also be among the first to receive the L403A1. The ‘Alternative Individual Weapon’ essentially fulfils the same role every AR-pattern rifle in UK service has since the 1960s.

New Alternative Individual Weapon – L403A1 (UK MoD)

The UK’s Minister for Defence Procurement, James Cartlidge said:

“This is another example of how we are committed to investing in the most advanced battlefield equipment to back our troops on the battlefield. This advanced rifle’s ability to help soldiers maintain the stealth edge not only protects them but delivers war-fighting advantage over our adversaries.”

Interestingly, the UK Ministry of Defence’s press release emphasises that as an AR-pattern rifle the L403A1 “shares much in common with the rifle systems used by many of the UK’s allies. Given their specialist role, and the critical task of working with and alongside many of the UK’s allies, the platform will enable ASOB to share skills and drills in an efficient manner.”

Close up of the Vortex and Aimpoint optics which make up part of the AIW package (Royal Marines/Royal Navy)

So what does the Alternative Individual Weapon (AIW) system include?

The system builds around the Knight’s KS-1 but also includes a magnified 1-10 LPVO optic from Vortex, an Aimpoint ACRO P-2 red dot and the Knight’s QDC/MCQ-PRT suppressor.  The prime contractor for the project, Edgar Brothers, are responsible for the sourcing and assembly of the AIW’s accessories. Accessories for the rifle will include a MAGPUL M54 sling, a Surefire Mini Scout Light Pro, G10 rail scales and a MAGPUL M-LOK AFG.

Anatomy of the L403A1 (Edgar Brothers)

The KS-1 is the latest iteration of the SR-16 series, it has a 13.7in (35cm) barrel and weighs 6.88lbs (3.1kg) unloaded, its overall length is 32.2in (82cm) with the stock collapsed and 34.2in (87cm) extended. The QDC/MCQ-PRT weighs an additional 13.9oz and adds just over 2 inches to the weapon’s length. The rifle uses a direct gas impingement system (or more correctly described as Stoner’s internal piston system).

The selection of the new rifle forms part of the Royal Marines’ larger modernization push under the Commando Force Programme alongside a new helmet from Gentex and Fused Binocular Night Vision devices from L3Harris.

Surveillance and Reconnaissance Squadron member with L403A1 in Norway (Royal Marines/Royal Navy)

We got our first indication of the KS-1’s selection in June, when the Royal Marines published a new recruitment advert featuring the rifle. It was also subsequently seen during a demonstration at Lulworth Ranges in July.

While the British military have used AR-pattern rifles since the 1960s in various roles, Project Hunter and the Alternative Individual Weapon represents a major procurement and it remains to be seen how it will influence Project Grayburn – the effort to select a replacement for more than 150,000 SA80s.

Support Us: If you enjoyed this video and article please consider supporting our work here. We have some great perks available for Patreon Supporters – including early access to custom stickers and early access to videos! Thank you for your support!

Bibliography:

Alternative Individual Weapon (AIW) System Tender Aug. 2021, UK Govt. (source)

£90 million contract equips Armed Forces with advanced new rifle, UK MoD (source)

Britain’s Commandos to get new assault rifles, Royal Navy (source)

Knight’s KS-1, Knight’s Armament Company, (source)

UK Selects New Assault Rifle, Overt Defense, (source) [This article is adapted from this original article]
